EUCHNER GmbH + Co. KG CIA3SX1R1G08
CIA3SX1R1G08
Технические характеристики
| yellow | ACTIVE LED data carrier active |
|---|---|
| green | STATE LED operational |
| Connection cross section | 0.14 ... 2.5 mm² |
| Output current | 10 mA |
| Напряжение питания | 20 ... 24 ... 28 V DC (All the electrical connections must either be isolated from the mains supply by a safety transformer according IEC/ EN 61558-2-6 with limited output voltage in the event of a fault, or by other equivalent isolation measures.) |
| without load | 65 ... 100 mA |
| Connection type | plug-in screw terminals |
| Number of read heads | max. 1 |
| Storage temperature | -25 ... 70 °C |
| Cable length | max. 5 m with RS232, max. 1,000 m with RS422 |
| Mounting type | Mounting rail TH 35 (EN IEC 60715) |
| Degree of protection | IP20 |
| Рабочая температура | 0 ... 55 °C |
| Housing | PA 6.6 |
| Data protocol | 3964R via RS232/RS422 |
| Data rate | 9600 ... 28800 kbit/s selectable via DIP switches |
| with s = 3 mm write distance | 2 mm (for surface mounting of the write-read head and the data carrier in a non-metallic environment) |
| at s = 3 mm read distance | 2.5 mm (for surface mounting of the write-read head and the data carrier in a non-metallic environment) |
| with center offset m=0 | 0 ... 3 ... 6 mm (These values apply for the surface installation of the read/write head and flush installation of the data carrier in non-metallic surroundings. For the flush installation of the data carrier in ferrous metals, the value is max. 5.5 mm and in aluminum max. 4.5 mm.) |
| Ordernumber | 077910 |
| Масса | 0,205kg |
| Customs tariff number | 85364110 |
| ECLASS 11.0 | 27-28-04-01 Identification, RFID Reader |
