EUCHNER GmbH + Co. KG CIT3APL1G05ST
CIT3APL1G05ST
Технические характеристики
| Output type | Push-pull |
|---|---|
| Напряжение питания | 20 ... 24 ... 28 V DC (All the electrical connections must either be isolated from the mains supply by a safety transformer according IEC/ EN 61558-2-6 with limited output voltage in the event of a fault, or by other equivalent isolation measures.) |
| per output | -30 ... +30 mA |
| Current consumption | 90 ... 120 mA without load current |
| Resistance | 4.5 kΩ Input resistance |
| Connection type | M12 plug, 8-pin, axial connection (The screen on the connecting cable is connected to the read head's screen bonding clamp via the knurled nut on the M12 plug connector.) |
| Storage temperature | -25 ... 70 °C |
| Mounting type | surface |
| Degree of protection | IP65 |
| Рабочая температура | 0 ... 50 °C |
| Housing | Plastic |
| Date interface | 4-bit parallel, binary coded via HIGH/LOW level |
| at 25 °C | 14 ... 20 ... 28 mm (It is necessary to maintain the minimum distance on the approach of the data carrier from the side so that data transfer to the read head functions correctly.) |
| at 25 °C, read distance | 13 mm |
| Ordernumber | 077805 |
| Масса | 0,388kg |
| Customs tariff number | 85389099990 |
| ECLASS 11.0 | 27-28-04-01 Identification, RFID Reader |
