EUCHNER GmbH + Co. KG CMS-R-BZB-01P-AS1
CMS-R-BZB-01P-AS1
Технические характеристики
| Operating distance on | min. 7 mm |
|---|---|
| Secured switch-off distance s ar | 40 mm |
| ASI operating current | max. 30 mA |
| red | Fault |
| green | Power |
| AS-Interface protocol | ASi-3 |
| ASI data in | D0 - D3 = door position |
| AS-Interface slave type | ID-Code: B, EA-Code: 0 |
| DC | 26.5 ... 30 ... 31.6 V |
| Connection type | hard-wired encapsulated cable with plug connector M12 |
| Design | B |
| Installation orientation | any |
| Storage temperature | -25 ... 70 °C |
| Cable length | 1 m |
| Mechanical life | 100 x 10⁶ |
| after change in the actuation status | max. 5 ms |
| Degree of protection | IP67 |
| Рабочая температура | -20 ... 60 °C |
| Housing | Reinforced thermoplastic (PPS), fully encapsulated |
| Материал | PUR |
| Method of operation | magnetic, reed contact |
| Ordernumber | 105094 |
| Масса | 0,085kg |
| Customs tariff number | 85389099990 |
| ECLASS 11.0 | 27-27-24-02 Safety-related magnetic proximity switch |
