EUCHNER GmbH + Co. KG HWA100T100A05/V10
HWA100T100A05/V10
Технические характеристики
| Output type | RS422 |
|---|---|
| Напряжение питания | in accordance with RS422A |
| Напряжение питания | 5 V DC -10% ... +10% |
| Pulses per revolution | 2x100 |
| without load | max. 80 mA |
| Connection type | Screw terminals, 6-pin |
| Storage temperature | -25 ... 70 °C |
| (condensation not permissible) | 80 % rH |
| Mechanical life | 1 x 10⁶ |
| Detent positions per revolution | 100 |
| according to NEMA | 250-12 (in the installed state) |
| Рабочая температура | 0 ... 50 °C |
| Материал | Plastic |
| Detent mechanism | mechanical |
| Control panel thickness | 1.5 - 2.0mm |
| Ordernumber | 072970 |
| Масса | 1,265kg |
| Customs tariff number | 85365019000 |
| ECLASS 11.0 | 27-24-23-07 Command-, control-, signal appliance |
