EUCHNER GmbH + Co. KG MSM-1-R-CKS2-FLX-A0Q0FS-R8-176626
MSM-1-R-CKS2-FLX-A0Q0FS-R8-176626
Технические характеристики
| Current consumption | max. 50 mA |
|---|---|
| Breaking capacity | max. 0.25 W |
| Напряжение питания | 24 V |
| Switching current | 5 ... 10 mA |
| LED power supply | 24 V DC |
| Electrical connection values - Breaking capacity | max. 0.25 W |
| Напряжение питания | 5 ... 24 V |
| Electrical connection values - Switching current | 1 ... 100 mA |
| Installation orientation | any |
| Storage temperature | -25 ... 70 °C |
| Время отклика | See operating instructions for bus module MBM-... or interlocking/locking module MGB2-I.-BR-... / MGB2-L.-BR-... |
| Shock and vibration resistance | Acc. to EN IEC 60947-5-3 |
| Degree of protection | IP65 (IP20) (IP65: only in the screwed tight state with the specified base units.) |
| at U B = 24 V DC | -25 ... 55 °C |
| Материал | Fiber glass reinforced plastic |
| Submodulbreite | 1 |
| Software ID (SW ID) | 9000065 |
| Ordernumber | 176626 |
| Масса | 0,115kg |
| Customs tariff number | 85371098 |
| ECLASS 11.0 | 27-24-26-05 Field bus, decentralized peripheral - function-/technology module |
