EUCHNER GmbH + Co. KG NZ1RS-3131-M-EX
NZ1RS-3131-M-EX
Технические характеристики
| Fuse | max. 4 A gG |
|---|---|
| Connection cross section | 0.34 ... 1.5 mm² |
| Напряжение питания | 50 V |
| Напряжение питания | 2.5 kV |
| DC-13 | 4 A 24 V |
| AC-15 | 4 A 50 V |
| Напряжение питания | 12 V |
| min. at DC 24V | 1 mA |
| thermal rated current I th | 4 A |
| Degree of contamination (external, according to EN 60947-1) | 3 |
| Anfahrgeschwindigkeit | 0.1 ... 20 m/min |
| 1 x | Cable entry M20 x 1.5 |
| Number of NO contacts | 2 |
| Number of door position positively driven contacts | 2 |
| Slide bearing metal | Roller plunger |
| Actuating force | 30 N |
| Installation orientation | any |
| Clamping range for cable | 6.5 ... 12 mm |
| Storage temperature | -25 ... 75 °C |
| Mechanical life | 30 x 10⁶ |
| Roller diameter | 12 mm |
| Switching principle | Slow-action switching contact |
| Degree of protection | IP67 |
| Рабочая температура | -20 ... 75 °C |
| Housing | Anodized die-cast alloy |
| Contact | Silver alloy, gold flashed |
| Explosion protection in accordance with ATEX Directive 2014/34/EU | II3G Ex nR IIB T5 Gc X / II3D Ex tc IIIC T100°C Dc |
| Ordernumber | 094169 |
| Масса | 0,427kg |
| Customs tariff number | 85365019000 |
| ECLASS 11.0 | 27-27-26-01 Safety position switch (Type 1) |
