EUCHNER GmbH + Co. KG RPS-C-538SR95M-174757
RPS-C-538SR95M-174757
Технические характеристики
| Fuse | max. 4 A gG |
|---|---|
| Connection cross section | 0.34 ... 1.5 mm² |
| rated conditional short-circuit current | 400 A |
| Напряжение питания | 400 V |
| Напряжение питания | 4 kV |
| DC-13 | 24 V 1.5 A |
| AC-15 | 240 V 3 A |
| Safety class | II |
| thermal rated current I th | 5 A |
| Degree of contamination (external, according to EN 60947-1) | 3 |
| 1 x | M20 x 1.5 |
| Number of positively driven contacts | 2 |
| Actuating force | 95 N |
| Installation orientation | any |
| Storage temperature | -40 ... 80 °C |
| Mechanical life | 0.1 x 10⁶ |
| Degree of protection | IP66/IP67 |
| Rope diameter | 2 ... 5 mm |
| Рабочая температура | -30 ... 75 °C |
| Emergency stop | Reinforced thermoplastic |
| Housing/cover | Reinforced thermoplastic |
| Материал | Silver |
| Ordernumber | 174757 |
| Масса | 0,312kg |
| Customs tariff number | 85365019000 |
| ECLASS 11.0 | 27-37-12-01 Emergency stop pull cord switch |
