EUCHNER GmbH + Co. KG RPS-M-2131SR175M
RPS-M-2131SR175M
Технические характеристики
| Fuse | max. 6 A gG |
|---|---|
| Connection cross section | 0.5 ... 1.5 mm² |
| Напряжение питания | 250 V |
| Напряжение питания | 2.5 kV |
| AC-15 | 3A 240V / 6A 120V |
| DC-13 | 0.27A 250V / 0.55A 125V |
| at 24V | min. 10 mA |
| Safety class | I |
| thermal rated current I th | 10 A |
| 3 x | M20 x 1.5 |
| Number of NO contacts | 1 |
| Number of positively driven contacts | 3 |
| Actuation frequency | max. 1200 1/h |
| Actuating force | 175 N |
| Installation orientation | any |
| Storage temperature | -30 ... 80 °C |
| Mechanical life | 0.1 x 10⁶ |
| Switching principle | Slow-action switching contact |
| Degree of protection | IP67 |
| Rope diameter | 2 ... 5 mm |
| Рабочая температура | -30 ... 80 °C |
| Housing | Die-cast aluminum |
| Additional feature | Emergency stop function |
| Ordernumber | 171992 |
| Масса | 0,799kg |
| Customs tariff number | 85365019000 |
| ECLASS 11.0 | 27-37-12-01 Emergency stop pull cord switch |
