α D21LiB5 ADV Plus
Технические характеристики
| Axis Travel (X/Y/Z) | 700/400/400 mm |
|---|---|
| Table Size X | 850 mm |
| Table Size Y | 410 mm |
| Max Table Load | 400 kg |
| Machine Mass | 2350 kg |
| Max Tool Length | 250 mm |
| Max Tool Diameter | 80 mm |
| Max Tool Mass | 4 kg |
| Total Mass | 46 kg |
| Number of Tools | 21 |
| Max Programmable Cutting Feed | 30000 mm/min |
| Tool Change Time | 0.7 s |
| Air Pressure | 72 psi / 0.5 MPa |
| Distance Spindle Nose to Table | 80-480 mm |
| Spindle Speed | 24000 High Speed min⁻¹ |
| Spindle Holder | BBT30 |
| X-Axis Rapid Traverse | 54 m/min |
| Y-Axis Rapid Traverse | 54 m/min |
| Z-Axis Rapid Traverse | 54 m/min |
| Axis Positioning Accuracy | < 0.006. mm |
| Axis Positioning Repeatability | <0.004. mm |
