JUMO GmbH & Co. KG 705113
JUMO I/O system analog input module, 4-channel
Технические характеристики
| Inputs | 4 universal analog inputs for RTD temperature probes (two-wire, three-wire, or four-wire); thermocouples and standard signals (0(4) to 20 mA, 0 to 1 V, or 0 to 10 V); resistance transmitters; optional: high-precision thermocouple; current/voltage (high-speed), or RTD temperature probes only (two-wire, three-wire, or four-wire) |
|---|---|
| Connection | Terminal strips with PUSH IN technology on the front |
| Special features | Each of the 4 inputs can be configured with 2 limit value monitoring functions, the cycle time of the module can be configured, switching statuses are visualized with LEDs; quick wiring of operating voltage and system bus by simply plugging the modules together; space-saving design; operation with JUMO variTRON and in combination with earlier JUMO I/O modules (7050xx) possible; increased vibration and shock resistance through optional connection rails |
| Approvals | DNV; UL |
| Напряжение питания | DC 24 V +25/-20 %, supply via central processing unit with system module 705171 (JUMO variTRON 500) or communication module 3-channel 705163 (JUMO variTRON 300, JUMO variTRON 500 touch, third-party products) |
| Housing | Plastic housing for DIN-rail mounting in the control cabinet |
| Protection type | IP20 |
| Рабочая температура | -20 to +55 °C |
| Dimensions (W × H × D) | 12 × 106.7 × 101 mm (without connection elements) |
