JUMO GmbH & Co. KG 902455
JUMO HEATtemp
Технические характеристики
| Connection | Ferrules |
|---|---|
| Connecting cable | PVC, PUR, TPE, silicone; unshielded or shielded |
| Process connection | Type DS: screw connection M10 × 1, brass according to DIN EN 1434, type DL: thread G 1/4, G 1/2 stainless steel |
| Protection tube | Stainless steel |
| Temperature sensor | Pt100, Pt500, or Pt1000 |
| Temperature | 0 to 120 °C (cold) 0 to 180 °C (heat) |
| Minimum immersion depth | Type DS: 15 mm, type DL: 30 mm |
| Insertion length | Type DS: 25 to 60 mm, type DL: 60 to 280 mm |
| Protection type | IP65 |
| Option | Two-wire or four-wire circuit |
| Special features | Type examination certificate for heat meter MID and domestic approval for combined cold/heat meters as exchangeable temperature probes; fulfils the requirements of DIN EN 1434, AGFW FW 202, and FW 211; pairing and declaration of conformity according to the German Weights and Measures Act (MessEG) and MID; production certified according to module D (MID) (CE and metrology identification marking) |
| Accessories | Ball valves have proven to be the optimum installation location (902442) |
