SICK AG LVM5532
Profiling systems LVM5532
Технические характеристики
| Features (Number of covered lanes) | 1 |
|---|---|
| Features (Vehicle data) | Residual load volume Vehicle classes Driving direction Lane assignment Confidence level for all vehicle datas 3D point cloud Vehicle dimensions |
| Features (Sensor) | 2D LiDAR sensor |
| Features (Recommended distance between max. vehicle height and sensor) | ≥ 1 m |
| Features (Stop-and-go functionality) | Yes |
| Features (Max. range with 10 % reflectivity) | 40 m |
| Features (Aperture angle) | 190°, per LMS511 SE |
| Features (Laser class) | 1, eye-safe (IEC 60825-1:2014) |
| Features (Heating) | ✔ |
| Features (Internal computer) | Application Processing Unit (APU) ✔ |
| Features (Internal memory) | 256 GB SSD |
| Mechanics/electronics (Installation position) | Overhead or at the side |
| Mechanics/electronics (Installation height) | 5 m ... 8 m At least 1 m higher than the maximum vehicle height |
| Performance (Minimum object size) | 1 m x 0.6 m x 0.6 m (L x W x H) |
| Performance (Maximum object size) | 32 m x 3.5 m x 5 m (L x W x H) |
| Performance (Minimum detectable object) | 190 mm x 130 mm x 130 mm |
| Interfaces (Output data) | Vehicle data incl. load volumes |
| General notes (Items supplied) | LMS511 HD (3 x) Application Processing Unit (APU) LVM software |
| Сертификация | ✔ |
| Сертификация | ✔ |
| Classifications (ECLASS 5.1.4) | 27280190 |
| Classifications (ECLASS 6.0) | 27280190 |
| Classifications (ECLASS 7.0) | 27280190 |
| Classifications (ECLASS 8.0) | 27280190 |
| Classifications (ECLASS 9.0) | 27280190 |
| Classifications (ECLASS 10.0) | 27280190 |
| Classifications (ECLASS 11.0) | 27280190 |
| Classifications (ECLASS 12.0) | 27280190 |
| Classifications (ECLASS 13.0) | 27280190 |
| Classifications (ECLASS 14.0) | 27280190 |
| Classifications (ECLASS 15.0) | 27280190 |
| Classifications (ETIM 6.0) | EC002550 |
| Classifications (ETIM 7.0) | EC002550 |
| Classifications (ETIM 8.0) | EC002550 |
| Classifications (ETIM 9.0) | EC002550 |
| Classifications (ETIM 10.0) | EC002550 |
| Classifications (UNSPSC 091201.0) | 41111615 |
| Classifications (UNSPSC 100501.0) | 41111615 |
| Classifications (UNSPSC 111201.0) | 41111615 |
| Classifications (UNSPSC 120901.0) | 41111615 |
| Classifications (UNSPSC 131201.0) | 41111615 |
| Classifications (UNSPSC 140801.0) | 41111615 |
| Classifications (UNSPSC 151101.0) | 41111615 |
| Classifications (UNSPSC 160901.0) | 41111615 |
| Classifications (UNSPSC 171001.0) | 41111615 |
| Classifications (UNSPSC 180801.0) | 41111615 |
| Classifications (UNSPSC 190501.0) | 41111615 |
| Classifications (UNSPSC 200601.0) | 41111615 |
| Classifications (UNSPSC 210901.0) | 41111615 |
| Classifications (UNSPSC 220601.0) | 41111615 |
| Classifications (UNSPSC 230701.0) | 41111615 |
| Classifications (UNSPSC 240301.0) | 41111615 |
| Classifications (UNSPSC 250901.0) | 41111615 |
| Classifications (UNSPSC 260801.0) | 41111615 |
