SICK AG PS600W-3PH12132524Z
Power supply units and power supply cables PS600W-3PH12132524Z
Категории:
Технические характеристики
| Features (Product segment) | Power supply units and power supply cables |
|---|---|
| Features (Product) | Power supply units |
| Features (Technology) | Fully encapsulated AC/DC power supply unit |
| Features (Further functions) | 600 W continuous power Full power up to +50 °C Wide input voltage range Safety and error protection functions Rugged, industrial-grade full metal housing |
| Features (Cooling method) | Contact/conduction cooling (without fan) |
| Features (Optical indicators) | LED, multi-colored (AC-OK) LED, multi-colored (DC-OK) |
| Features (Description) | Fully encapsulated AC/DC power supply unit, 600 W, 24 V DC, 25 A, 380 V AC ... 480 V AC, AC input: M12, 4-pin plug, S-coded, DC output: M12, 5-pin socket, L-coded |
| Features (MTTFd) | 28.5 years 1) |
| Напряжение питания | AC input |
| Напряжение питания | 380 V AC ... 480 V AC |
| Electronics (Input frequency) | 50 Hz / 60 Hz |
| Electronics (Frequency range) | 47 Hz ... 63 Hz |
| Electronics (Inrush current) | 25 A, at 528 V AC 1) |
| Electronics (Efficiency (at full load)) | 92.5 % @ 380 V AC |
| Electronics (Power factor (at full load)) | 0.95 @ 380 V AC |
| Напряжение питания | DC output |
| Напряжение питания | 24 V DC |
| Напряжение питания | 24 V DC ... 30 V DC |
| Electronics (Output current) | 20 A |
| Electronics (Maximum output current) | ≤ 25 A |
| Electronics (Maximum output power) | ≤ 600 W |
| Electronics (Ripple) | 1 % 2) |
| Electronics (Monitoring signal) | DC-OK |
| Степень защиты (IP) | IP67 (in mounted condition) |
| Electronics (Protection class) | I |
| Напряжение питания | Protective functions in the event of errors |
| Electronics (Overcurrent) | Shutdown with automatic recovery |
| Electronics (Short-circuit) | Shutdown with automatic recovery |
| Напряжение питания | Shutdown in interlock mode (manual restart required) |
| Electronics (Overtemperature) | Shutdown with automatic recovery |
| Mechanics (Connections AC input 1 x M12, 4-pin plug, S-coded DC output 1 x M12, 5-pin female connector, L-coded) | Connections |
| Mechanics (AC input) | 1 x M12, 4-pin plug, S-coded |
| Mechanics (DC output) | 1 x M12, 5-pin female connector, L-coded |
| Материал | Cover: Aluminum alloy ADC12 Base plate: aluminum A5052 |
| Mechanics (Housing color) | Cover: natural finish, sand-blasted |
| Масса | 1,856 g |
| Mechanics (Dimensions (L x W x H)) | 265 mm x 112 mm x 78 mm |
| Mechanics (Mounting system type) | Fitting, 6 mounting holes |
| Ambient data (Ambient operating temperature) | –40 °C ... +50 °C |
| Ambient data (Ambient temperature, storage) | –40 °C ... +85 °C |
| Ambient data (Operating altitude) | Up to 3,048 m |
| Ambient data (Storage height) | Up to 9,144 m |
| Ambient data (Relative humidity Operation 20 % ... 90 %, Non-condensing Storage 10 % ... 95 %, Non-condensing) | Relative humidity |
| Ambient data (Operation) | 20 % ... 90 %, Non-condensing |
| Ambient data (Storage) | 10 % ... 95 %, Non-condensing |
| Сертификация | ✔ |
| Сертификация | ✔ |
| Сертификация | ✔ |
| Classifications (ECLASS 5.1.4) | 27270906 |
| Classifications (ECLASS 6.0) | 27270906 |
| Classifications (ECLASS 7.0) | 27270906 |
| Classifications (ECLASS 8.0) | 27270906 |
| Classifications (ECLASS 9.0) | 27270906 |
| Classifications (ECLASS 10.0) | 27270906 |
| Classifications (ECLASS 11.0) | 27270906 |
| Classifications (ECLASS 12.0) | 27270906 |
| Classifications (ECLASS 13.0) | 27270906 |
| Classifications (ECLASS 14.0) | 27270906 |
| Classifications (ECLASS 15.0) | 27270906 |
| Classifications (ETIM 6.0) | EC001820 |
| Classifications (ETIM 7.0) | EC001820 |
| Classifications (ETIM 8.0) | EC001820 |
| Classifications (ETIM 9.0) | EC001820 |
| Classifications (ETIM 10.0) | EC001820 |
| Classifications (UNSPSC 091201.0) | 39121528 |
| Classifications (UNSPSC 100501.0) | 39121528 |
| Classifications (UNSPSC 111201.0) | 39121528 |
| Classifications (UNSPSC 120901.0) | 39121528 |
| Classifications (UNSPSC 131201.0) | 39121528 |
| Classifications (UNSPSC 140801.0) | 39121528 |
| Classifications (UNSPSC 151101.0) | 39121528 |
| Classifications (UNSPSC 160901.0) | 39121528 |
| Classifications (UNSPSC 171001.0) | 39121528 |
| Classifications (UNSPSC 180801.0) | 39121528 |
| Classifications (UNSPSC 190501.0) | 39121528 |
| Classifications (UNSPSC 200601.0) | 39121528 |
| Classifications (UNSPSC 210901.0) | 39121528 |
| Classifications (UNSPSC 220601.0) | 39121528 |
| Classifications (UNSPSC 230701.0) | 39121528 |
| Classifications (UNSPSC 240301.0) | 39121528 |
| Classifications (UNSPSC 250901.0) | 39121528 |
| Classifications (UNSPSC 260801.0) | 39121528 |
