SICK AG SOPAS-ENGINEERING-TOOL-64-BIT
Engineering Tools SOPAS Engineering Tool 64 bit
Технические характеристики
| Features (Description) | Newest SOPAS Engineering Tool version. This download is approximately 400 MB in size and contains the Setup.exe for installing SOPAS ET. It does not contain any SDDs (SOPAS Device Drivers). SDDs can be downloaded once SOPAS ET has been started up for the first time. Use the device catalog for this purpose. If the SDDs are not available on a data card, they are loaded from the Internet. This requires an Internet connection. SDDs can be downloaded selectively. Please note: ● We recommend establishing a fixed wire connection to the fast Internet. ● After the conditions for use have been accepted and the download has been initiated, select the SAVE option in the displayed window. ● Double-click the saved Setup.exe file. ● Then select Execute and Install. |
|---|---|
| Features (Description of the application) | As soon as it starts, SOPAS ET configuration software begins searching for connected SICK sensors and displays them. Detected sensors can be selectively integrated into the project. SOPAS ET automatically establishes a connection and pulls up suitable drivers. If none are available, they are loaded from the Internet or directly from the sensor. There is no need for extensive searches and installation of drivers. Sensors are presented clearly as tiles or lists. Double-clicking on a tile opens a window for configuring the sensor. Assistants and integrated workflows provide support. Additional tools such as device comparison, data recorders, terminals as well as sensor emulators round off the range of functions. The multi-device window facilitates the handling of projects which contain many devices, thereby completely replacing Version 2.38.3. This view can only be used for devices which were not developed using JavaFX. These are mostly devices which do not follow the new UI Guideline. |
| Features (Language) | Multilingual |
| System requirements (Operating system) | Windows 10 (64 bit) Windows 11 |
| System requirements (Required disk space) | 450 MB Plus additional storage space for additional components (device drivers) |
| System requirements (Interface) | Hardware communication channels such as serial interface, USB or Ethernet depending on the SICK device (e.g. Ethernet, universal serial bus (USB) or RS-232 (serial connection)) |
| System requirements (Monitor) | Min. 256 colors – 65,536 colors recommended (16-bit high color) |
| System requirements (Processor) | X86- or x64-compatible processor, Minimum: Intel Gen6 or equivalent |
| System requirements (Graphics processor (GPU)) | Supports OpenGL 4.3 (required for SOPAS device drivers that contain 3D components) |
| System requirements (Frequency and RAM) | 1 GB RAM |
| System requirements (Minimum screen resolution) | 1,024 px x 768 px (For some device drivers, the required minimum display size may vary) |
| Classifications (ECLASS 5.1.4) | 0 |
| Classifications (ECLASS 6.0) | 0 |
| Classifications (ECLASS 7.0) | 0 |
| Classifications (ECLASS 8.0) | 0 |
| Classifications (ECLASS 9.0) | 13030490 |
| Classifications (ECLASS 10.0) | 13030490 |
| Classifications (ECLASS 11.0) | 13030490 |
| Classifications (ECLASS 12.0) | 13030490 |
| Classifications (ECLASS 13.0) | 13030490 |
| Classifications (ECLASS 14.0) | 13030490 |
| Classifications (ECLASS 15.0) | 13030490 |
| Classifications (ETIM 6.0) | EC000809 |
| Classifications (ETIM 7.0) | EC000809 |
| Classifications (ETIM 8.0) | EC000809 |
| Classifications (ETIM 9.0) | EC000809 |
| Classifications (ETIM 10.0) | EC000809 |
| Classifications (UNSPSC 091201.0) | 43232600 |
| Classifications (UNSPSC 100501.0) | 43232600 |
| Classifications (UNSPSC 111201.0) | 43232600 |
| Classifications (UNSPSC 120901.0) | 43232600 |
| Classifications (UNSPSC 131201.0) | 43232600 |
| Classifications (UNSPSC 140801.0) | 43232600 |
| Classifications (UNSPSC 151101.0) | 43232600 |
| Classifications (UNSPSC 160901.0) | 43232600 |
| Classifications (UNSPSC 171001.0) | 43232600 |
| Classifications (UNSPSC 180801.0) | 43232600 |
| Classifications (UNSPSC 190501.0) | 43232600 |
| Classifications (UNSPSC 200601.0) | 43232600 |
| Classifications (UNSPSC 210901.0) | 43232600 |
| Classifications (UNSPSC 220601.0) | 43232600 |
| Classifications (UNSPSC 230701.0) | 43232600 |
| Classifications (UNSPSC 240301.0) | 43232600 |
| Classifications (UNSPSC 250901.0) | 43232600 |
| Classifications (UNSPSC 260801.0) | 43232600 |
